Vial washing–sterilization-filling -stoppering linkage line
Ampoule washing-sterilization -filling-sealing linkage line
Oral liquid bottle washing-sterilization -filling-capping linkage line
Freeze drying system solution
The linkage line consists of HQCLA series vertical ultrasonic washing machine, HSDH series hot air circulation sterilization tunnel, HSFG series filling and stoppering machine. The model can be used in combination or in a single machine. The linkage line can complete water spray filling, ultrasonic cleaning and flushing (internal and external), CA flushing (internal and external), preheating, drying and sterilizing to remove heat source, cooling, filling, sealing, capping and other processes etc.This line can meet the size ranging from 2-30ml vials of washing, drying and sterilizing to remove heat source, filling and sealing requirements of the production process.
Vertical ultrasonic washing machine using ultrasonic rough washing, circulating water, WFI and clean compressed air sprays and cleans the container alternately. Cleaning clarity and visible material detection effect is ideal; It is one of the most popular cleaning machine in the world today.The sterilization tunnel adopts the principle of hot air laminar flow and high temperature sterilization process to preheat, dry, sterilize, remove heat and sterilization process. It is one of the most popular drying and sterilizing machines in the world.The filling and stoppering machines adopts V shape block to transfer and reciprocating tracking filling which can ensure stable vials transfer, full time of filling and accurate filling volume, using the way of progressive stoppering to ensure high qualification rate. It is one of the most popular filling and sealing machines in the world.The interlocking production line adopts PLC control and touch screen operation, which can be used for linkage control or stand-alone operation. The control runs stably and with high automation.
